Best Drop Side Cargo Trailers: 60 Ton 3 Axle Options

Short Description:

ELITE 60 ton load 3 axle drop side cargo trailer is designed with detachable side walls which is easy for loading and unloading. It can be attached to HOWO, Shacman, Dongfeng, Beiben, Volvo, Scania and Benz truck head, suitable for heavy load and long distance hauling.

Send email to us

Product Detail

Product Tags

ELITE 60 ton drop side cargo trailer features,

1. Light weight and heavy load

2. Strong structure can go across rough roads easily

3. One year warranty

4. Fast production and quick shipping

5. Can be customized with customer’s logo and brand

ELITE 60 ton drop side cargo trailer specification,

Model	3 axle 60 ton drop side cargo trailer
Dimension	13,000×2,500×2,700mm
Weight	8,500kg
Load capacity	60,000kg
Axle	3×13 ton
Tires	12.00R20, 12R22.5
King pin	2 or 3.5 inch
Suspension	Mechanical suspension, air suspension as option
Main beam	The height of the beam is 500mm, upper plate 14mm, down plate 16mm, middle plate 8mm.
Landing gear	28 ton
Brake system	Dual line brake system, six chambers
Electric system	24v, 7 ways
Side wall	detachable
